Name: DJI Matrice 4D Worry-Free Flagship Combo
SKU: 5671
Availability: InStock

Description

High-Performance Drones

The all-new water and dust-resistant DJI Matrice 4D and 4TD are specifically designed for DJI Dock 3, offering extended flight time, and can pair with DJI RC Plus 2 Enterprise for standalone use. Both drones are equipped with a wide-angle camera, a medium tele camera, a tele camera and a Laser Range Finder. Matrice 4D is highly effective for professional high-precision mapping and detailed surface inspections. Matrice 4TD is equipped with an infrared thermal camera and a new NIR auxiliary light, making it suitable for a wide range of applications such as infrastructure inspections, emergency response, and public safety.

DJI Matrice 4D

Wide-Angle Camera

4/3 CMOS
20MP Effective Pixels
f/2.8-f/11
24mm Format Equivalent
Mechanical Shutter

Medium Tele Camera

1/1.3-inch CMOS
48MP Effective Pixels
f/2.8
70mm Format Equivalent

Tele Camera

1/1.5-inch CMOS
48MP Effective Pixels
f/2.8
168mm Format Equivalent

Laser Range Finder

Measurement Range: 1800 m (1 Hz);
Oblique Incidence Range (1: 5 Oblique Distance): 600 m (1 Hz)
Blind Zone: 1 m
Range Accuracy (m): ± (0.2 + 0.0015 × D)

Obstacle Sensing for Safe Operation

The Obstacle Sensing Module [4] for Matrice 4D/4TD combines rotating LiDAR and millimeter-wave radar technologies for precise 12mm wire-level obstacle avoidance at speeds up to 15 m/s in complex power line crossings, as well as enhanced positioning in low-light conditions. Operational safety are ensured for varying environments of power distribution network and the intricate layouts of substations.

Excels in Low-Light Environments

Matrice 4D Series drones feature four high-resolution, low-light fisheye lenses, significantly enhancing visual low-light positioning and obstacle sensing capabilities. The new Night Scene mode offers full-color night vision. Matrice 4TD additionally provides IR-Cut Filter feature for black-and-white night vision and 24/7 operations, as well as a new NIR auxiliary light that can cover distances up to 100 m.

Matrice 4TD’s infrared thermal camera supports the UHR Infrared Image mode with image resolutions up to 1280 × 1024 and a High-Res mode for detailed temperature readings.

Clear Vision and Stable Images

Matrice 4D Series drones are equipped with medium tele and tele cameras with foreground stabilisation. The medium tele camera is effective for medium-range inspections, detecting pins and cracks from 10 meters, and clearly reading instrument data at substations. The 48 MP tele camera captures details, like signs, from up to 250 m away. When using Matrice 4TD’s tele camera as the aircraft is hovering in a windless environment, the gimbal can tilt upwards by 80 degrees, making bridge underside defects clearly visible. Upgraded stabilisation keeps foreground subjects clear during telephoto shots at 10x zoom or higher.

High-Precision Surveying

Matrice 4D Series drones excel in high-precision mapping, offering a new 5-direction oblique photography function, 3-direction orthophoto photography, and real-time terrain following to meet various mapping requirements. DJI FlightHub 2 has been upgraded for Matrice 4D/4TD operations. This upgrade introduces a range of flight route planning options, including Smart 3D Capture routes [5], geometric routes, and slope routes, enhancing efficiency while ensuring detailed modeling.

Seamless Airborne Relay for Mountainous Terrains

Matrice 4D Series can operate with the DJI RC Plus 2 Enterprise remote controller for standalone use while featuring an innovative onboard relay function. With this setup, one drone can fly high as a relay, allowing another drone to operate at a greater distance. The relay drone automatically faces the operating drone, ensuring smooth video transmission without a 4G signal or in obstructed conditions. This capability significantly extends the transmission range, making it ideal for SAR tasks and inspections in mountainous areas.

How many versions does the DJI Matrice 4D Series have? What are the differences between them?

DJI Matice 4D Series currently includes two versions – DJI Matrice 4D and DJI Matrice 4TD.

DJI Matrice 4D is equipped with a 4/3 CMOS 20MP wide-angle camera, a 1/1.3-inch CMOS 48MP medium tele camera, a 1/1.5-inch CMOS 48MP tele camera, and a laser range finder, providing powerful imaging capabilities.

DJI Matrice 4TD is equipped with a 1/1.3-inch CMOS 48MP wide-angle camera, a 1/1.3-inch CMOS 48MP medium tele camera, a 1/1.5-inch CMOS 48MP tele camera, a infrared thermal camera, an NIR auxiliary light, and a laser range finder. It features powerful thermal imaging and low-light imaging capabilities.
