Description

The Briteq LED PLANO12-6in1 is a high-performance flat LED projector equipped with 12 powerful 20W RGBLA+UV LEDs, delivering vibrant and full-spectrum color mixing with additional ultraviolet output for dramatic effects. Designed for versatility and mobility, this fixture is ideal for DJs, rental companies, events, and clubs. Whether you’re using it as a standalone unit with built-in programs, controlling it via DMX, or synchronizing it across multiple units in master/slave mode, the PLANO12-6in1 adapts seamlessly to any application.

Its compact and lightweight design, combined with low power consumption and a robust double bracket for easy floor placement, makes it perfect for both permanent installations and portable use. It also supports wireless DMX operation via an optional WTR-DMX dongle, giving you complete cable-free control. A user-friendly OLED display simplifies menu navigation, while the included IR remote offers quick and easy access to built-in modes and settings.

12 x 20W high-output RGBLA + UV LEDs for rich and diverse color effects

6-in-1 color mixing with added amber and UV for enhanced warmth and vibrancy

Compatible with wireless DMX via optional WTR-DMX dongle

IR remote control included for easy standalone use

Supports standalone, sound active, auto, master/slave, DMX, and remote modes

DMX control with multiple channel modes for fine color and effect control

OLED display for intuitive navigation

Double bracket allows use as a floor spot or truss mounting

0–100% smooth dimming and ultra-fast strobe functionality

LEDCON-XL and LEDCON-02 Mk2 compatibility (limited RGB control in Mk2 mode)

Ideal for mobile applications and small-to-medium installations

Specifications
Light Source

LED Type: 12 x 20W RGBLA+UV

Color Mixing: Red, Green, Blue, Lime, Amber + UV

Beam Angle: Wide (not specified)

Control

Control Modes: Standalone (fixed, sound, auto), Remote (IR), Manual, DMX, Master/Slave

Protocols: DMX, Wireless DMX (WTR-DMX ready)

DMX Channels: Multiple modes (details via manual)

Compatible Controllers: LEDCON-XL, LEDCON-02 Mk2 (RGB only)

Display: OLED for easy menu navigation

Included Remote: IR Remote

Power & Physical

Power Input: AC 100–240V, 50/60Hz

Power Consumption: 107W

Dimensions: 31 x 28.5 x 11.5 cm

Weight: 3.6 kg

IP Rating: IP20 (indoor use only)

Mounting: Double bracket (floor or truss), M12 fixation point

Housing Color: Black
